Recordings

Flight Library

Every IRIG 106 Chapter 10 recording indexed by sortie, test article and time, with limit exceedances flagged from its parameter dictionary.

Drop Chapter 10 files (.c10, .ch10) here, or choose files.

Dictionary

Sortie	Date	Article	Test	Duration	Size	Data	Limits

Bellerophon Enterprise

Why Bellerophon

Built for government and commercial flight test programs that need post-flight data reduction, data quality assessment, test point evaluation and fleet-wide search in one validated library. Bellerophon Enterprise installs on servers your organization controls and decodes your Chapter 10 recordings with your parameter dictionaries. This evaluation shows the same analysis on four synthetic demonstration flights.

Your Data Stays on Your NetworkInstalls on customer-controlled servers, makes no outbound connections and loads no external resources, so it runs on closed networks. Recordings and decoded data are never sent to LNB Federal.

Reader Cross-Checked Against Independent ReadersThe Chapter 10 reader passes 67 of 67 validation checks on published sample recordings, with results compared against two independent open-source readers, pychapter10 and irig106lib. Sync patterns and header checksums are verified on every packet.

Proven on Full-Size RecordingsA 2.6 GB recording with 13.7 million 1553 messages and 45.6 million PCM frames processed at 57 MB/s with 379 MB peak memory.

Major Chapter 10 Data Types, One Time AxisMIL-STD-1553, PCM, ARINC 429, discretes, analog and Ethernet (IENA and iNET-X), decoded to engineering units and plotted together on IRIG time at the full recorded rate.

Security Controls for AssessorsSmart card (CAC/PIV) sign-in, viewer, engineer and administrator roles, an audit log, a FIPS mode and a security approval package for assessors. Each customer authorizes its own use.

No Third-Party CodeRuns on Node.js 22.5 or later with no third-party packages, which keeps the software supply chain small. Each release includes a software bill of materials. Deploys as a system service or a container.

Capabilities

Features

Chapter 10 IngestRecordings stream to the server and decode with flat memory use, so recordings of tens of gigabytes process on ordinary hardware. Packet sync and header checksums are verified on every packet; a damaged packet is skipped and reading resumes at the next valid packet.

MIL-STD-1553Format 1 decoded at word level: 16-bit and 32-bit values and bit fields, matched by channel, RT address, T/R bit and subaddress. Block status word errors are counted, and messages flagged with a message error are excluded.

PCMFormat 1 in packed, unpacked and throughput modes, decoded from the TMATS frame definition, including words of different lengths. Throughput streams are framed by sync pattern search; subcommutated parameters are located through the subframe ID word.

ARINC 429Labels in octal with bit-reversed transmission handled, BNR and discrete fields, SDI and bus selection. Words the recorder flags with parity or format errors are excluded.

Time, TMATS and DiscretesTime Format 1 places every packet on the IRIG time line through the 10 MHz relative time counter. TMATS is decoded, including PCM format groups and the recorder channel map. Discretes decode as single bits or multi-bit fields.

Analog and EthernetAnalog Format 1 decoded per subchannel when all subchannels share one sample rate, sample length (up to 32 bits) and packing mode. Parameters in IENA positional and fixed-layout iNET-X packets carried in UDP decoded by key or stream ID and position, as integers or floating point values.

Parameter DictionariesImported from the recording's TMATS setup record or from CSV, with linear or polynomial conversions and limits. Every row is validated, and a TMATS import previews every measurement it could not import, with the reason.

Derived ParametersCalculated parameters such as Mach number, unit conversions and filtered signals, written as expressions with arithmetic, logic and functions including a low-pass filter, rate of change, integral and delay. They search, plot and export like recorded parameters.

Data Quality ReportEvery recording receives a data quality rating from checks on time, packets, PCM sync and subframes, 1553 errors and dropouts, and each parameter, so problems in the data are found before analysis starts.

Time History PlotsStacked charts on a shared time axis with an IRIG time readout and drag to zoom. Min/max rendering keeps single-sample spikes visible, and multi-level summaries keep full-flight views fast.

Library-Wide SearchUp to four above/below conditions combined with AND and held for a minimum duration, run on full-resolution data across every recording in the library.

Limit MonitoringHigh and low limits per parameter. Samples outside a limit within 3 seconds of each other form one exceedance, reported with start time, duration and peak value.

Flight ComparisonOne parameter from up to four sorties overlaid on elapsed time, with minimum, maximum and mean for each.

Recorder Inventory1553 traffic by RT and subaddress, PCM stream status with sync errors, ARINC 429 labels, discretes, Ethernet flow summaries and the full TMATS text for each recording.

Test PointsTest points mark a time window of a recording with its test card and pass or fail criteria, evaluated automatically against every recorded sample and searchable across the library.

Post-Flight ReportA one-click report with plots, statistics, exceedances, data quality and test point results, printable to PDF on Letter or A4 paper, with report templates per program.

Ground TrackLatitude and longitude drawn as a ground track linked to the chart cursor, on a coordinate grid or on offline map tiles the customer supplies. Nothing is loaded from the internet.

Flight NotesEngineers add time-stamped notes to a flight, such as a test point, an abort or an observation. Notes are drawn on the time history and open the chart at that moment.

Data Export and APIThe selected parameters over the current time window, written as CSV at the full recorded rate. A read-only data access interface with personal access tokens and a Python client deliver time series as CSV or MATLAB files, and as HDF5 or Parquet files with standard Python packages. Every export and data request is audited.

Exceedance ReportEvery limit exceedance in the library with sortie, parameter, limit, IRIG start time, duration and peak, as a CSV file for test reports.

Full-Resolution StatisticsMinimum, maximum and mean in flight comparison are computed on the server from every recorded sample in the window, not from the plotted points.

Administration and AuditViewer, engineer and administrator roles, with password or smart card (CAC/PIV) sign-in. Sign-ins, user changes, uploads, dictionary changes, notes, exports and deletions are logged with the client address, and administrators export the full log as CSV for assessors.

Evaluation and Enterprise

What You Get with Enterprise

	Evaluation	Enterprise
Recordings	Four synthetic demonstration flights	Your IRIG 106 Chapter 10 recordings, up to 100 GB each by default (configurable)
Decoding	Pre-decoded at build time; no reader in the browser	Chapter 10 reader on your server: 1553, PCM, ARINC 429, discretes, analog, IENA and iNET-X, time and TMATS
Data Resolution	Minimum and maximum of each 0.4 s interval	Every sample at the recorded rate
Parameter Dictionaries	Demonstration dictionary only	Your dictionaries, imported from TMATS or CSV, with derived parameters, matched by TMATS program name
Data Quality and Test Points	Not available	A data quality rating for every recording, and test points evaluated automatically against their criteria
Reports	Not available	One-click post-flight reports, printable to PDF
Users	One browser tab, no accounts	Shared team library with viewer, engineer and administrator roles
Notes and Exports	Not available	Time-stamped flight notes, CSV export at the full recorded rate, a read-only data access interface with a Python client, library exceedance report and audit log export
Security	Runs in your browser; nothing is transmitted	Smart card (CAC/PIV) sign-in, FIPS mode, sign-in throttling, session controls, audit log with client addresses, system use notification, a security approval package, no outbound connections
Deployment	None	Your server on Node.js 22.5 or later, as a system service or a container
Warranty and Support	Provided as is	90-day limited warranty and support through the contact named in your order

Licensing

Pricing

Every tier includes every Enterprise capability, software updates and support for the full term. Tiers differ only in active users and servers, so a customer never pays to unlock a feature.

Pilot

Up to 5 Users · One Server · 90 Days

Bellerophon Enterprise on your own recordings and dictionaries, to validate results against your current tools. The pilot fee is credited in full toward a first-year license ordered within 60 days of the pilot end date.

Pricing on Request

Team

Up to 10 Users · One Server

A shared flight library for a single test team or test article program.

Pricing on Request

Program

Up to 50 Users · Two Servers

Multiple test teams on one library with role-based access and a common audit log, plus a second server for test, training or continuity of operations.

Pricing on Request

Enterprise

51+ Users · Multiple Servers and Sites

Test wings, ranges and centers on one agreement, with servers and sites set by the order and priority support.

Pricing on Request

Term: annual licenses, available as a base year with up to four option years, or as a multi-year term.
Growth: additional users in blocks of five and additional servers can be added at any time, co-terminous with the current license.
Deployment: installed on customer servers, including isolated and air-gapped networks. No usage reporting and no connection to LNB Federal.

Request a Quote Capability Statement Brochure

For Customers

How Licensing Works

Bellerophon Enterprise is licensed per organization for a fixed term and number of users, and runs on servers the customer controls. LNB Federal Corporation does not host it, and the software never contacts LNB Federal or any license server.

1. Request a QuoteChoose a pilot or a tier, the number of users and servers, and the term. Pilots run 90 days on the customer's own recordings, and the pilot fee is credited toward the first year. Licenses are annual, with option years or a multi-year term.

2. Secure DeliveryThe software package arrives through a file transfer service the customer approves, such as DoD SAFE, with its SHA-256 checksum sent separately so the customer can confirm it was not altered.

3. Install on Your ServersThe customer installs Bellerophon on Linux (recommended), Windows Server or macOS with Node.js 22.5 or later, or as a container, behind its own HTTPS certificate. No internet access is needed.

4. Activate the LicenseLNB Federal sends a license file naming the customer, order, tier, users and term. An administrator installs it under Users & Audit. It is verified offline by its digital signature.

5. During the TermFull use. A renewal notice appears 90 days before the end date (14 days for a pilot), so there is time for a renewal order, and a 30-day grace period follows the end date.

6. Renewals and UpgradesA renewal or more users is a new license file, installed the same way; nothing is reinstalled. If a license lapses, browsing, plots, search and data export continue, so the customer always keeps access to its data.

Licensing overview: Bellerophon Enterprise Documentation, section 6.

Flight detail

Flight Detail

Time History

Drag across the chart to zoom. Double-click to reset. Shaded bands mark limit exceedances.

Ground Track

Recorder Channels

Ch	Data type	Packets	Size

TMATS setup record

Analysis

Search & Limits

Find every moment across the library that meets a test condition. Conditions are combined with AND and must hold for the minimum duration.

Quick Searches

Sortie	Start (IRIG)	Elapsed	Duration	Peak

Limit Monitoring

Limits come from each recording's parameter dictionary and are checked when the recording is loaded. Readings within 3 seconds of each other count as one exceedance.

Parameter	Limit	Flights checked	Exceedances	Sorties

Analysis

Compare Flights

Overlay one parameter from up to four sorties on elapsed time from start of recording.

Parameter

Sortie	Min	Max	Mean	Samples

Configuration

Parameter Dictionaries

A dictionary tells Bellerophon where each measurement lives in the recording and how to convert it to engineering units. Recordings use the dictionary whose program name matches their TMATS program, or the one you choose.

Name	Program	Parameters	Sources	With limits

CSV Format

One row per parameter. 1553 data words and PCM frame words start at 1. ARINC 429 labels are octal. Bit positions start at 0 for the least significant bit.

Column	Meaning

Administration

Users & Audit

Admins manage accounts and roles. Engineers upload recordings and dictionaries. Viewers analyze data.

Name	Email	Role	Status

Audit Log

Time (UTC)	User	Action	Detail

Bellerophon 1.1.0

Documentation

Bellerophon Evaluation 1.1.0 · Evaluation Guide · LNB Federal Corporation · October 2026

1. Overview

Bellerophon is a flight test data platform developed by LNB Federal Corporation. It reads IRIG 106 Chapter 10 flight test recordings, converts recorded measurements into engineering units using a parameter dictionary, and gives a test team one shared library in which to plot parameters on a common time axis, search every flight for test conditions, and find limit exceedances.

The Bellerophon Evaluation edition lets engineers and program staff see how Bellerophon works before requesting a license. It runs in a web browser, needs no installation or account, and comes with four synthetic demonstration flights already processed.

Bellerophon is available to government agencies and to companies, universities and other organizations. Use of this edition is governed by the Evaluation Terms.

In short: this edition shows the analysis workflow on sample data. It cannot open your own recordings. To evaluate Bellerophon on your program's data, request a pilot of Bellerophon Enterprise (section 10).

2. Evaluation and Enterprise Compared

Capability	Evaluation edition	Bellerophon Enterprise
Flight library, time history plots, ground track	Yes, demonstration flights	Yes, your recordings
Library-wide search and limit monitoring	Yes	Yes
Flight comparison	Yes	Yes
Recorder inventory: 1553, PCM, ARINC 429, discretes, TMATS	Yes, for the demonstration flights	Yes
Open your own Chapter 10 recordings	No	Yes, any size, streamed to the server
Import your own parameter dictionaries	No (the demonstration dictionary can be viewed)	Yes, from TMATS or CSV, with row-by-row validation
Derived (calculated) parameters	No	Yes
Analog, IENA and iNET-X data; PCM throughput mode	No	Yes
Data quality rating for every recording	No	Yes
Test points with pass or fail criteria	No	Yes
One-click post-flight report	No	Yes, printable to PDF
Data access for MATLAB and Python	No	Yes, CSV export and a read-only interface with a Python client
Sample resolution	Reduced (see section 7)	Full recorded rate
Multiple users, roles, audit log, sign-in banner	No	Yes
Smart card (CAC/PIV) sign-in and FIPS mode	No	Yes
Where it runs	Your web browser	A server on your network, with no outside connections

3. Before You Start

Browser: a current version of Chrome, Edge, Firefox or Safari. Nothing is installed.
Notice: when the page opens, read the evaluation notice. Select I accept only if you are authorized to accept the terms for yourself or your organization and agree to the Evaluation Terms. If you select Decline, the software does not open.
Data: you do not need any data. The four demonstration flights load automatically. Do not type, paste or upload classified, controlled or program information into this page.

4. The Demonstration Flights

All demonstration data is synthetic. It was generated by LNB Federal to resemble a typical instrumented test aircraft and does not represent any real aircraft, program, test or flight.

Sortie	Date	Test article	Test card	Duration	Limit exceedances
FT-2611	2026-09-14	TA-01	Envelope expansion, Mach 0.60 to 0.95 at 30,000 ft	38 min	None
FT-2612	2026-09-16	TA-01	Handling qualities, wind-up turns to 5 g at 15,000 ft	32 min	Normal load factor peaked at 5.2 g against a 5.0 g limit
FT-2613	2026-09-21	TA-02	Stall approaches, clean configuration at 20,000 ft	30 min	None
FT-2614	2026-09-23	TA-01	Functional check flight after engine change	35 min	Exhaust gas temperature peaked at 878 °C against an 850 °C limit; fan vibration peaked at 1.23 in/s against a 1.0 in/s limit

Instrumentation of the Demonstration Aircraft

Recorder channel	Data type	Content
3	MIL-STD-1553	Air data, inertial and propulsion messages from remote terminals 5, 6 and 7: altitude, airspeed, Mach, vertical speed, angle of attack, outside air temperature, attitude, heading, normal load factor, latitude and longitude, fan and core speed, exhaust gas temperature, fuel flow, fuel quantity, oil pressure. 10 samples per second.
4	PCM	Engine monitoring stream, 16 words per minor frame, 100 minor frames per second: fan and core vibration, hydraulic pressures A and B, and the subcommutated generator voltage and load (subframe ID in word 1).
5	ARINC 429	GPS altitude (label 076) and GPS ground speed (label 112).
6	Discrete	Weight on wheels, landing gear down, master caution.

Monitoring limits in the demonstration dictionary: angle of attack above 18°, normal load factor above 5.0 g, exhaust gas temperature above 850 °C, and fan vibration above 1.0 in/s.

5. Guided Walkthrough

These five tasks show the main workflow in about ten minutes.

Find the engine exceedances. On Flight Library, select FT-2614. Under Limit Exceedances, select the exhaust gas temperature event. The chart zooms to the event; the dashed red line is the 850 °C limit and the shaded band is the time above it.
Read values at one instant. Add Fan speed N1 and Fuel flow from the parameter list. Hover over the chart: the readout shows every plotted value at the cursor, in IRIG time and elapsed time.
Search the whole library. Open Search & Limits and run the quick search Load factor above 4 g. Bellerophon searches all four flights and returns the two wind-up turns in FT-2612 that held above 4 g for at least one second. Select a result to open the flight at that moment.
Compare flights. Open Compare, choose Exhaust gas temperature, and select FT-2611 and FT-2614. The overlay shows FT-2614, flown after the engine change, peaking at 878 °C, above the 850 °C limit, while FT-2611 stays below 815 °C. The table gives minimum, maximum and mean for each flight.
See where the data comes from. Return to Flight Detail and scroll to the recorder inventory. The 1553 table lists each remote terminal and subaddress with its message rate; the PCM table shows the frame format and sync errors; the TMATS record is shown in full. Open Dictionaries to see how each parameter is mapped and scaled.

6. Reading the Displays

Time History

Each parameter is drawn in its own lane on a shared time axis. Drag across the chart to zoom; double-click or select Reset zoom to return to the full flight. When a lane covers more samples than the chart has pixels, Bellerophon draws the minimum and maximum of the samples under each pixel column, so short spikes stay visible.

Time

Absolute time is shown in IRIG format DDD:HH:MM:SS.sss, where DDD is the day of the year. Elapsed time counts from the start of the recording.

Search

Each condition tests whether a parameter is above or below a threshold. All conditions must be true at the same time for at least the minimum duration. The first condition reports its peak value within each matching interval.

Limits

Samples outside a limit that occur within 3 seconds of each other are reported as one exceedance, with its start, duration and peak.

7. Data Resolution in This Edition

To keep the page small, the demonstration flights are stored at reduced resolution. Bellerophon Enterprise always works at the full recorded rate.

Each parameter is stored as the minimum and maximum of every 0.4-second interval, which gives 5 points per second and preserves peaks.
Values are stored with 16-bit precision over each parameter's range for that flight. For example, altitude is resolved to better than 1 ft.
The limit exceedances listed for each flight were computed from the full-rate data before reduction, so they match what Bellerophon Enterprise reports.
Searches in this edition run on the reduced data. Start and end times of search results can differ from a full-rate search by up to 0.4 seconds.

8. Data Handling and Security

The Evaluation edition contains only synthetic demonstration data and cannot open, import or upload files.
It sends nothing to LNB Federal. It uses no cookies, accounts or analytics.
Your acceptance of the evaluation notice is remembered in this browser (local storage) for 30 days, then requested again; declining clears it.
The page loads the Lato and IBM Plex Mono fonts from Google Fonts. Google receives your network address when the fonts load, under Google's own privacy terms.
The website that hosts the Evaluation edition has its own privacy statement.

Not for operational use: the Evaluation edition is for assessment only. Do not use it, or anything it displays, for flight safety, airworthiness, certification or mission decisions.

9. Glossary

ARINC 429: An avionics data bus. Each 32-bit word carries an 8-bit label, written in octal, that identifies the data.
Chapter 10: IRIG 106 Chapter 10, the Range Commanders Council standard for digital flight data recorders.
Dictionary: The table that tells Bellerophon where each parameter is in the recording and how to convert it to engineering units. Programs often call this a parameter list or an instrumentation database.
Engineering units: Physical units such as feet, knots or degrees Celsius, as opposed to raw counts.
Exceedance: A period during which a parameter is above its high limit or below its low limit.
IRIG time: Day of year, hours, minutes and seconds, from the recorder's time source.
MIL-STD-1553: A military command/response data bus. Remote terminals (RT) transmit (T) or receive (R) data words at subaddresses (SA).
PCM: Pulse code modulation telemetry: a serial stream of fixed-length words arranged in repeating minor frames.
Subcommutated parameter: A PCM parameter that appears in a given word position only in some minor frames, identified by the subframe ID (SFID) word.
TMATS: The setup record at the start of a Chapter 10 recording that describes its channels and formats.

10. Moving to Bellerophon Enterprise

To evaluate Bellerophon on your own data, LNB Federal offers a pilot of Bellerophon Enterprise installed on your customer's network. To prepare, have the following ready:

One or more representative Chapter 10 recordings from the program, handled under your customer's data rules.
The program's parameter list or instrumentation database, in any format. Bellerophon Enterprise can build a dictionary from the TMATS setup record in the recordings, and LNB Federal can help convert other formats.
A host that meets the requirements in the Bellerophon Enterprise documentation, and the point of contact for its authorization.

An overview of Bellerophon Enterprise is published at https://lnbfederal.com/bellerophon/docs/. The complete guide is delivered with the licensed software.

LNB Federal Corporation

Legal Notices and License Terms

LNB Federal Corporation, a Delaware corporation. These notices apply to the Bellerophon software, including the Bellerophon Evaluation edition and Bellerophon Enterprise (together, the "Software"), and to its documentation. Last updated October 11, 2026 (revision 4: on lnbfederal.com, acceptance of the evaluation notice is remembered in the browser for 30 days).

How to Read These Notices

Each section below states the legal terms first. Where a section is followed by a box marked In plain terms, that box explains what the section means in practice for engineers and program staff. The plain-language explanations are provided for convenience only. They are not part of the terms, and if an explanation differs from the terms, the terms control. Contracting officers and legal counsel should rely on the terms themselves and on the applicable order.

Eligible Customers

LNB Federal Corporation ("LNB Federal") makes the Software available to government departments and agencies, companies, universities, research institutions and other organizations (each an "Eligible Customer"), subject to the Export Control Notice below, which currently limits delivery of Bellerophon Enterprise to Eligible Customers located in the United States. LNB Federal does not provide the Software to any person, country or end use prohibited by U.S. export control or sanctions laws, screens each customer against U.S. restricted party lists before delivery, and may decline to provide the Software to any person at its discretion and in accordance with applicable law. A contractor or consultant may use the Software on behalf of an Eligible Customer that holds a license or, for the Evaluation edition, that has authorized the evaluation.

In plain terms: Bellerophon is available to government agencies and to companies, universities and other organizations. Bellerophon Enterprise is currently delivered only to customers in the United States while its export classification is pending, and every order is checked against U.S. export and sanctions rules before delivery. Contractors can use it for work they are doing for a licensed customer. For questions about eligibility, contact webmaster@lnbfederal.com.

Bellerophon Evaluation Terms

These terms govern the Bellerophon Evaluation edition made available through https://lnbfederal.com (the "Evaluation Edition"). By selecting "I accept," you agree to these terms on behalf of yourself and the organization you represent, and you confirm that you are authorized to accept them for that organization, or that you are evaluating the Software for yourself as an individual. If you do not agree, or if you are not so authorized, select "Decline" and do not use the Evaluation Edition.

1. Evaluation license. LNB Federal grants you a limited, non-exclusive, non-transferable, revocable, royalty-free license to use the Evaluation Edition solely to assess whether you or your organization will license the Software. The license ends when LNB Federal withdraws the Evaluation Edition.

2. Demonstration content only. The Evaluation Edition contains synthetic demonstration flights and a demonstration parameter dictionary generated by LNB Federal. They do not represent any real aircraft, program, test or flight. The Evaluation Edition stores the demonstration data at reduced resolution, as described in the Evaluation Guide, and cannot open recordings or import parameter dictionaries.

3. No operational use. You may not use the Evaluation Edition, or any result it displays, for flight safety decisions, airworthiness determinations, certification, mission planning or any other operational purpose.

4. Restrictions. You may not copy, modify, distribute, sell, sublicense, frame or host the Evaluation Edition for others; remove or alter any notice; use it to build a competing product; or reverse engineer, decompile or disassemble it, except to the extent applicable law expressly permits despite this restriction.

5. Information you enter. Do not enter classified information, Controlled Unclassified Information, export-controlled technical data or program information into the Evaluation Edition. The Evaluation Edition does not transmit information to LNB Federal.

6. Feedback. If you provide comments or suggestions about the Software, LNB Federal may use them without obligation to you. Do not include classified, controlled or proprietary information in feedback.

7. No warranty. The Evaluation Edition is provided "as is" and "as available," without warranty of any kind, express or implied, including any implied warranty of merchantability, fitness for a particular purpose, accuracy or non-infringement.

8. Limitation of liability. To the maximum extent permitted by applicable law, LNB Federal will not be liable for any indirect, incidental, special, consequential or punitive damages, or for loss of data, arising from use of the Evaluation Edition, and its total liability arising from the Evaluation Edition will not exceed one hundred U.S. dollars (US $100).

9. Government users. Nothing in these terms obligates appropriated funds, requires a government user to indemnify LNB Federal, or applies to a government user to the extent it is inconsistent with federal law or with the user's national law. If a provision is unenforceable against a government user, the remaining provisions continue to apply.

10. Export. Your use is subject to the Export Control Notice below.

11. Governing law. For U.S. Government users, these terms are governed by the federal law of the United States. For all other users, these terms are governed by the laws of the State of Delaware, without regard to conflict of law rules, and the state and federal courts located in the State of Delaware have exclusive jurisdiction over any dispute arising from them.

In plain terms: you may use the Evaluation edition to decide whether your organization wants Bellerophon. It works only with made-up sample flights stored at reduced resolution, so do not use anything it shows for a real flight, safety or certification decision, and do not type real program data into it. Do not copy it, host it elsewhere or take it apart. It comes with no warranty, and LNB Federal's liability for it is capped at $100. Nothing here commits government funds or overrides federal law.

Bellerophon End User License Agreement

This End User License Agreement (the "Agreement") is between LNB Federal and the Eligible Customer identified in the applicable order, contract, task order, purchase order or other signed ordering document (the "Order") (the "Licensee"). It applies to Bellerophon Enterprise and to any version of the Software delivered under an Order. For U.S. Government licensees, this Agreement is the commercial license under which the Software is offered, and it applies only to the extent consistent with federal law and the Order.

1. Definitions. "Software" means the Bellerophon software in object and script form, including updates delivered under the Order. "Documentation" means the user, administration and security documentation LNB Federal provides for the Software. "Authorized Users" means employees of the Licensee and contractors acting on its behalf whom the Licensee authorizes to use the Software. "Licensee Data" means recordings, dictionaries, decoded data and other information the Licensee processes with the Software.

2. License grant. Subject to this Agreement and payment of the fees in the Order, LNB Federal grants the Licensee a non-exclusive, non-transferable license, for the term, site and quantity stated in the Order, to install the Software on systems the Licensee controls and to permit Authorized Users to use the Software and Documentation for the Licensee's internal business or governmental purposes. The Licensee may make a reasonable number of copies for backup, disaster recovery, testing and security assessment.

3. Restrictions. Except as this Agreement or applicable law expressly permits, the Licensee will not (a) sell, rent, lease, sublicense or distribute the Software to any person who is not an Authorized User; (b) use the Software to provide services to persons other than the Licensee, including as a hosted service or service bureau, unless the Order permits it; (c) modify the Software, except for configuration described in the Documentation; (d) reverse engineer, decompile or disassemble the Software; or (e) remove or alter proprietary, export or legal notices. Nothing in this section limits rights the U.S. Government holds by statute or under the Order.

4. Ownership. The Software is licensed, not sold. LNB Federal and its licensors retain all right, title and interest in the Software and Documentation, including all intellectual property rights. The Licensee retains all right, title and interest in Licensee Data.

5. Licensee Data. The Software runs on infrastructure the Licensee controls and does not transmit Licensee Data to LNB Federal. LNB Federal will access Licensee Data only if the Licensee gives access in writing for a support purpose, and will then protect it as the Order and applicable law require.

6. Support and updates. LNB Federal will provide the support, maintenance and updates stated in the Order. Unless the Order states otherwise, support includes correction of reproducible defects and updates released during the paid support term.

7. Limited warranty. LNB Federal warrants that, for ninety (90) days after delivery, the Software will perform substantially as described in the Documentation. The Licensee's exclusive remedy for breach of this warranty, and LNB Federal's sole obligation, is for LNB Federal to correct the nonconformity, replace the Software or, if neither is commercially reasonable, end the license for the nonconforming Software and refund the fees paid for it. The warranty does not apply to nonconformities caused by modification, misuse, or use with hardware, software or data not described in the Documentation.

8. Disclaimer. Except for the express warranty in section 7 and any warranty the Order requires, the Software and Documentation are provided without any other warranty, express or implied, including implied warranties of merchantability, fitness for a particular purpose and non-infringement. LNB Federal does not warrant that the Software will be error free or that results will be accurate for every recording. The Licensee is responsible for verifying results before relying on them for flight safety, airworthiness or other critical decisions.

9. Limitation of liability. To the extent permitted by applicable law, neither party will be liable to the other for indirect, incidental, special, consequential or punitive damages, or for lost profits or data, and LNB Federal's total liability arising from this Agreement will not exceed the fees paid for the Software in the twelve (12) months before the claim arose. These limits do not apply to LNB Federal's obligations under section 10, to liability for fraud, bodily injury or death caused by negligence, or to any liability that cannot be limited under applicable law, including 31 U.S.C. §§ 3729–3733.

10. Infringement. LNB Federal will defend the Licensee against third-party claims that the Software, as delivered, infringes a United States patent, copyright or trademark or misappropriates a trade secret, and will pay resulting damages finally awarded or settlements LNB Federal approves. For U.S. Government licensees, the defense of any claim is subject to the authority of the U.S. Department of Justice under 28 U.S.C. § 516, and LNB Federal may participate at its own expense. If the Software is or may become subject to such a claim, LNB Federal may obtain the right for the Licensee to continue using it, modify it to be non-infringing, or end the license and refund the unused prepaid fees.

11. Term and termination. This Agreement lasts for the term stated in the Order. For U.S. Government licensees, termination is governed by the Order and federal law, and disputes are resolved under the Contract Disputes Act, 41 U.S.C. §§ 7101–7109. For other licensees, either party may terminate for the other party's material breach that remains uncured thirty (30) days after written notice, unless the Order provides otherwise. When the license ends, the Licensee will stop using the Software and remove it from its systems, except for copies it must keep under law or records retention rules. Licensee Data remains the Licensee's property.

12. Export. Each party will comply with the export control and sanctions laws that apply to it, as described in the Export Control Notice.

13. Governing law. For U.S. Government licensees, this Agreement is governed by the federal law of the United States. For all other licensees, this Agreement is governed by the laws of the State of Delaware, without regard to conflict of law rules, and the state and federal courts located in the State of Delaware have exclusive jurisdiction over any dispute arising from it. The United Nations Convention on Contracts for the International Sale of Goods does not apply.

14. Government terms prevail. For U.S. Government licensees, any term of this Agreement that is inconsistent with federal law or with the Order, including any term that would require the Government to indemnify LNB Federal, renew automatically, pay taxes or fees not stated in the Order, or accept changes to this Agreement it has not signed, is unenforceable against the Government to that extent, consistent with FAR 52.212-4. The Order controls over this Agreement where they conflict.

15. General. This Agreement and the Order are the entire agreement on their subject. A waiver is effective only in writing. If a provision is unenforceable, the rest of the Agreement remains in effect. The Licensee may not assign this Agreement without LNB Federal's written consent, except as federal law permits. LNB Federal may assign it only as permitted by applicable law and the Order, including the novation requirements of FAR Subpart 42.12 for U.S. Government contracts.

In plain terms: your organization's order sets the term, the site and the number of users. Install Bellerophon on systems your organization controls and let your own people and your contractors use it for your own work. Do not resell it, run it as a service for others unless your order allows it, modify its code or take it apart. LNB Federal owns the software; your organization owns its recordings, dictionaries and results, and Bellerophon never sends them to LNB Federal. For 90 days after delivery LNB Federal will fix or replace the software if it does not work as documented. Engineers must still check results against the program's approved data reduction before using them for safety or certification decisions. If anyone claims the software infringes their rights, LNB Federal defends your organization (for a U.S. Government customer, subject to the Department of Justice's authority). For a U.S. Government order, federal law and the order itself always win over this agreement.

U.S. Government Rights

The Software is "commercial computer software" and the Documentation is "commercial computer software documentation," as those terms are used in FAR 2.101 and DFARS 252.227-7014. Under FAR 12.212 and DFARS 227.7202-1 and 227.7202-3, the U.S. Government and its contractors acquire the Software and Documentation only with the rights set out in the Bellerophon End User License Agreement, as modified by the Order. The contractor and manufacturer is LNB Federal Corporation, a Delaware corporation, CAGE 12WN4.

For government customers outside the United States, rights in the Software are those set out in the End User License Agreement and the Order, subject to that nation's procurement law.

In plain terms: Bellerophon was developed at private expense and is sold as a commercial product. A U.S. Government buyer receives the rights in the license agreement and the order, not unlimited or government-purpose rights in the source code.

Export Control Notice

The Software, the Documentation and related technical information may be subject to the U.S. Export Administration Regulations (15 C.F.R. Parts 730–774), U.S. economic sanctions administered by the Office of Foreign Assets Control (31 C.F.R. Chapter V), and the export laws of other countries. You may not export, re-export or transfer the Software, directly or indirectly, to any country, entity or person, or for any end use, prohibited by those laws, including to any person on the Entity List, the Denied Persons List or the Specially Designated Nationals and Blocked Persons List, or to any country or region subject to a comprehensive U.S. embargo.

LNB Federal reviews every order for export compliance and screens each customer against U.S. restricted party lists before delivery. A request for an official export classification of the Software has been filed with the U.S. Department of Commerce, Bureau of Industry and Security, and is pending. Until it is decided, LNB Federal supplies Bellerophon Enterprise only to Eligible Customers located in the United States and does not export, re-export or transfer it outside the United States. Contact webmaster@lnbfederal.com with any export question.

Flight test recordings and parameter dictionaries may themselves contain technical data controlled under the International Traffic in Arms Regulations (22 C.F.R. Parts 120–130) or the Export Administration Regulations. Users are responsible for handling their own data in compliance with those regulations.

In plain terms: do not send Bellerophon to a sanctioned country or a restricted party. Bellerophon Enterprise is currently supplied only to customers in the United States and must not be moved outside the United States, including to an allied country, while its export classification is pending; contact LNB Federal with any export question. Remember that your flight data and parameter lists may be export controlled even when the software is not; handle them under your program's export rules.

Classified Information and Safety of Flight

The Software has not been assessed or authorized for use on any information system under the Risk Management Framework, holds no authority to operate, and is not approved for processing classified national security information. Each Licensee is responsible for obtaining any authorization or security approval it requires before operational use and for operating the Software under its own security controls. The Evaluation Edition must not be used with classified information under any circumstances.

The Software is not a safety-of-flight system. It is not designed or certified for use in aircraft, flight control, real-time range safety or any application in which failure could lead to death, personal injury or severe property damage.

In plain terms: Bellerophon has no ATO yet. Your organization's security authority (for a government agency, its authorizing official) decides whether and where it may run. It is a post-flight analysis tool: never use it to control an aircraft or to make a real-time range safety call.

Data Handling and Privacy

Evaluation Edition. The Evaluation Edition contains only synthetic demonstration data, cannot open or upload files, and does not transmit information to LNB Federal. It uses no cookies, accounts or analytics. Your acceptance of the evaluation notice is remembered in this browser (local storage) for 30 days, then requested again; declining clears it. To display text, the page loads the Lato and IBM Plex Mono fonts from Google Fonts, which receives your network address when the fonts load, under Google's own privacy terms.

Bellerophon Enterprise. The Software runs on infrastructure the Licensee controls. It stores user names, email addresses, hashed passwords, session records, an audit log and Licensee Data on that infrastructure, makes no outbound network connections, and sends no telemetry to LNB Federal.

For the privacy statement governing the https://lnbfederal.com website, see the Privacy Statement on that site.

Trademarks and Standards

LNB Federal and the names of LNB Federal products are trademarks of LNB Federal Corporation. Other names are the property of their owners. IRIG 106 is published by the Range Commanders Council. MIL-STD-1553 is a U.S. Department of Defense standard. ARINC 429 is an aviation industry standard. References to standards, government organizations or NATO describe compatibility only and do not imply affiliation with, or endorsement by, the standards bodies, the U.S. Department of War, any other Government Agency or NATO.

Third-Party Notices

The Evaluation Edition displays the Lato typeface (Copyright Łukasz Dziedzic) and the IBM Plex Mono typeface (Copyright IBM Corp.), each licensed under the SIL Open Font License, Version 1.1. Bellerophon Enterprise contains no third-party code. It runs on the Node.js runtime, which the Licensee installs separately under the Node.js license. The container image in the Enterprise package is based on the official Node.js image, whose components are licensed by their respective owners.

LNB Federal tested the Software's Chapter 10 reader against the open-source pychapter10 library and its sample recordings (BSD 3-Clause License, Copyright Avionics Test and Analysis Corporation) and against the open-source irig106lib library (BSD license, Copyright Irig106.org). Those libraries and recordings are not distributed with the Software.

Capacidad	Edición de evaluación	Bellerophon Enterprise
Biblioteca de vuelos, gráficos de historia temporal, trayectoria sobre el terreno	Sí, vuelos de demostración	Sí, sus grabaciones
Búsqueda en toda la biblioteca y monitoreo de límites	Sí	Sí
Comparación de vuelos	Sí	Sí
Inventario del grabador: 1553, PCM, ARINC 429, discretas, TMATS	Sí, para los vuelos de demostración	Sí
Abrir sus propias grabaciones de Capítulo 10	No	Sí, de cualquier tamaño, transmitidas al servidor
Importar sus propios diccionarios de parámetros	No (se puede ver el diccionario de demostración)	Sí, desde TMATS o CSV, con validación fila por fila
Parámetros derivados (calculados)	No	Sí
Datos analógicos, IENA e iNET-X; modo de transferencia directa de PCM	No	Sí
Calificación de calidad de datos para cada grabación	No	Sí
Puntos de prueba con criterios de aprobación o rechazo	No	Sí
Informe posterior al vuelo con un clic	No	Sí, imprimible en PDF
Acceso a datos para MATLAB y Python	No	Sí, exportación CSV y una interfaz de solo lectura con un cliente de Python
Resolución de las muestras	Reducida (consulte la sección 7)	Frecuencia de grabación completa
Varios usuarios, roles, registro de auditoría, aviso de inicio de sesión	No	Sí
Inicio de sesión con tarjeta inteligente (CAC/PIV) y modo FIPS	No	Sí
Dónde se ejecuta	Su navegador web	Un servidor en su red, sin conexiones externas

Canal del grabador	Tipo de datos	Contenido
3	MIL-STD-1553	Mensajes de datos de aire, inerciales y de propulsión de los terminales remotos 5, 6 y 7: altitud, velocidad aerodinámica, Mach, velocidad vertical, ángulo de ataque, temperatura del aire exterior, actitud, rumbo, factor de carga normal, latitud y longitud, velocidad del fan y del núcleo, temperatura de los gases de escape, flujo de combustible, cantidad de combustible, presión de aceite. 10 muestras por segundo.
4	PCM	Flujo de monitoreo del motor, 16 palabras por trama menor, 100 tramas menores por segundo: vibración del fan y del núcleo, presiones hidráulicas A y B, y el voltaje y la carga del generador subconmutados (ID de subtrama en la palabra 1).
5	ARINC 429	Altitud GPS (etiqueta 076) y velocidad respecto al suelo GPS (etiqueta 112).
6	Discreta	Peso sobre ruedas, tren de aterrizaje abajo, precaución maestra.

Sign In

Flight Library

Why Bellerophon

Features

What You Get with Enterprise

Pricing

How Licensing Works

Flight Detail

Time History

Ground Track

Recorder Channels

Search & Limits

Quick Searches

Conditions

Limit Monitoring

Compare Flights

Parameter Dictionaries

Import a Dictionary

CSV Format

Users & Audit

Add a User

Audit Log

Documentation

1. Overview

2. Evaluation and Enterprise Compared

3. Before You Start

4. The Demonstration Flights

Instrumentation of the Demonstration Aircraft

5. Guided Walkthrough

6. Reading the Displays

Time History

Time

Search

Limits

7. Data Resolution in This Edition

8. Data Handling and Security

9. Glossary

10. Moving to Bellerophon Enterprise

Legal Notices and License Terms

How to Read These Notices

Eligible Customers

Bellerophon Evaluation Terms

Bellerophon End User License Agreement

U.S. Government Rights

Export Control Notice

Classified Information and Safety of Flight

Data Handling and Privacy

Trademarks and Standards

Third-Party Notices

Evaluation Declined

1. Descripción general

2. Comparación entre la evaluación y Enterprise

3. Antes de comenzar

4. Los vuelos de demostración

Instrumentación de la aeronave de demostración

5. Recorrido guiado

6. Cómo leer las visualizaciones

Historia temporal

Tiempo

Búsqueda

Límites

7. Resolución de los datos en esta edición

8. Manejo de datos y seguridad

9. Glosario

10. Paso a Bellerophon Enterprise

Cómo leer estos avisos

Clientes Elegibles

Términos de Evaluación de Bellerophon

Contrato de Licencia de Usuario Final de Bellerophon

Derechos del Gobierno de los EE. UU.

Aviso de Control de Exportaciones

Información clasificada y seguridad de vuelo

Manejo de datos y privacidad

Marcas y normas

Avisos de terceros
